Lifting Capacity | 10000lbs.(4500KG) |
Max. Lifting Height | 70.8"/1800mm |
Min. Height | 3.9"/100mm |
Height Overall | 110.9"/2818mm |
Width Overall | 140.4"/3565mm |
Outside Column | 124.8"/3170mm |
Inside Column | 110.2"/2800mm |
Dirve-Thru Clearance | 98.4"/2500mm |
Front Arm Reach(Min) | 29.5"/750mm(2 stages) |
Front Arm Reach (Max) | 46"/1170mm(2 stages) |
Rear Arm Reach(Min) | 29.5"/900mm(2 stages) |
Rear Arm Reach(Max) | 49.2"/1480mm(2 stages) |
Motor | 220VAC/60HZ/1PH/2.2KW |
Net Weight | 570KG (1,290 Lbs) |
| Package Dims | 113"x20"x25" (Inches) |
Installation Warning: Concrete must be a minimum of 5.9 in (150 mm) thick with a 3000 PSI rating for safe operation. Verify slab strength before installation.
