| Max. Lifting Capacity | 8000 lbs |
| Lifting Height: | 72.3" |
| Overall Width: | 81.1" |
| Lifting Time: | < 50 Seconds |
| Platform Length: | 58.9" |
| Platform Width: | 24.4" |
| Motor power: | 110 V/220,60 Hz,1 Ph,3.0 Hp(2.2KW) |
| Rated Oil Pressure: | 20MPa |
| Package Dims | (2 Crates) Lift: 78"x67"x9" (1,370 Lbs) Pump: 39"x21"x17" (115 Lbs) |
